2008 Kawasaki Ninja® ZX™-10R

08 Ninja ZX1000, Black

Now until October 31, 2010
Request a Quote Financing Calculator Request a Brochure Financing Form
Click here to view full image.
Lime Green / Flat Super Black
Click on a thumbnail to view larger image.Click on a thumbnail to view larger image.Click on a thumbnail to view larger image.Click on a thumbnail to view larger image.Click on a thumbnail to view larger image.Click on a thumbnail to view larger image.
View All ThumbnailsHide Thumbnails
Request a Quote Financing Calculator Request a Brochure Financing Form
  • OEM Overview
  • Specifications
  • Compare Models
  • Current Promotions

Overview

 Print Brochure

    4-Cylinder, DOHC Engine
    • Very compact, narrow and lightweight design
    • One-piece upper crankcase and cylinder casting saves more than two pounds and offers increased rigidity
    • Channels in the case route oil to various parts of the engine, eliminating oil lines and saving weight
    • Stacked triangular layout of crank axis, input shaft and output shaft reduces engine length and lowers the center of gravity
    • About two pounds cut from the engine with a lighter crankshaft that maintains the same inertial moment
    • Oil pump reduction ratio refined for lower friction
    • Water pump uses the same type impeller as the ZX-14 with pump rpm optimized for less friction
    • Lightweight Denso radiator with tightly packed cores
    • Specially designed internal fins on the liquid-cooled, aluminum oil cooler for high-efficiency heat dissipation
    Cylinder head
    • Reshaped intake ports, exhaust ports and combustion chambers improve flow efficiency and top-end power
    • Exhaust ports are narrower at the midpoint and larger at the opening
    • Exhaust valves reduced in diameter from 25.5 to 24.5mm
    • Cam profiles feature higher lift to deliver more power at high rpm and make it easier to tune the engine for racing
    Fuel Injection
    • New secondary fuel injectors improve top-end power output and power characteristics
    • Oval cross-sectioned throttle bodies replace the earlier round units, improve throttle response and allow more precise throttle control
    • Compact flat-type fuel pump from the ’07 ZX-6R takes up less fuel tank space and permits the same tank volume despite the additional space required for the secondary injectors
    Air intake
    • Ram air intake duct was reshaped to reduce intake noise and further improve intake efficiency
    • New larger airbox with improved accessibility and ease of maintenance
    • The new oval shaped velocity stacks deliver improved flow efficiency
    Ignition
    • Advanced ignition management system helps curtail sudden spikes in engine speed, enhancing the rider’s control of torque delivery
    • Sophisticated ECU logic based on extensive rider testing
    • Monitors throttle position, gear position and rate of RPM change, then adjusts ignition advance to help regulate torque production
    Exhaust system
    • New exhaust system features a pre-chamber under the engine to reduce exhaust noise, and minimize silencer volume
    • Palladium catalyzer ensures the ZX-10R meets Euro-III exhaust emissions standards
    • Single orthogonal, titanium silencer, along with the pre-chamber, lowers the bike’s center of gravity and improves exhaust efficiency
    6-Speed Transmission
    • Lower 1st, 4th and 5th gear ratios to suit the new power characteristics, giving improved power feel in the low and high-rpm ranges
    • Harder acceleration with an one tooth larger rear sprocket - final reduction ratio of 17/41
    • Easily adjustable back-torque limiting clutch
    Chassis
    • Optimized stiffness balance of the unique twin-spar frame achieved by reshaping the frame’s pressed parts, replacing concave pieces with convex pieces to alleviate stress concentrations
    • Wall thickness around the swingarm pivot was changed to increase rigidity
    • Ribbing added on the interior of the pivot plate where it joins the frame’s upper cross member to slightly slow down the frame feedback for a more accurate feel
    • Steering tube moved 10mm forward and length changed
    • Relocated swingarm pivot for a slight front-rear weight balance change
    Sub-frame
    • Two-piece, aluminum die-casting with lightweight construction
    • New narrow sub-frame layout contributes to the compact and slim rear of the bike
    • Mounted to the frame’s upper cross member, so rear suspension feedback is transmitted more directly to the rider
    Swingarm
    • Pressed beam swingarm delivers a level of feel and feedback unobtainable with a cast swingarm
    • New swingarm features a top-mounted stabilizer that contributes to the superb high-speed stability of the new chassis
    Suspension
    • DLC (Diamond Like Carbon) fork tube coating on the fully adjustable 43mm inverted fork improves fork action with less friction, smoother action and better road holding
    • Bottom mounted springs completely submerged in oil, offer reduced frothing and improving damping performance, fork action and road-following ability
    • New mounting location for the Uni-Trak® rear suspension linkage
    • Fully adjustable shock now features dual (low- and high-speed) compression damping, providing the fine-tuning needed for racing
    Brakes
    • New Tokico radial mount brake calipers fitted with dual pads for superb initial bite, increased control and a progressive feel
    • New 310mm petal discs with a 5.5mm disc thickness provide better heat dispersion so the brake feel remains constant and responsive during extended periods of heavy use
    • 220mm rear petal disc is gripped by a single-piston caliper
    Wheels
    • New lighter yet stiffer squeeze-cast wheels feature more precise dimensions with less wall thickness than the previous gravity-cast units
    Ergonomics
    • Redesigned rear frame, tank and seat offer increased contact with the bike and provide the rider very accurate feedback regarding chassis performance and road surface
    • More flared around its top, the new tank makes it easier for the rider to rest the inside of their arm on the tank when leaning into a turn
    • New seat is narrower in the front and shorter, front to back, for a slimmer riding position, a shorter reach to the pavement and excellent feedback from the chassis
    • Special rib on the end of new throttle under the grip rubber improves grip and feel
    Aerodynamic Bodywork
    • Top of the front cowl is shorter but has a slight step at the front to reduce wind blast on the rider’s shoulders and generates a laminar flow around the rider’s helmet for less turbulence at higher speeds
    • New front fender increases cooling efficiency by directing air toward the radiator
    • Recess added to the top of the fuel tank to accommodate the helmet’s chin so it’s easier to tuck in behind the new, flatter windscreen
    • Smaller fairing sides reduce the influence of side winds on the bike
    • Redesigned mirrors with integrated turn signals and Talbot-type reflecting surfaces are easily removable, for easy track riding prep
    • High mounting position of mirrors provides excellent rearward visibility and helps to minimize damage if the bike falls over
    • Flush-surface of the tail’s underside reduces turbulence at the rear of the bike and ensures laminar airflow around the seat
    • Larger rear inner fender keeps the bike cleaner and allows the mud flap to be smaller and less obtrusive, further improving aerodynamic qualities around the rear of the machine
    • License plate holder and rear turn signals are also quickly detachable for racing
    • New LED tail light makes the bike more visible to drivers and provides the final styling flourish to the evocative Ninja design
    Race-quality steering damper
    • Adjustable Öhlins steering damper with relief valve and twin-tube design, developed specifically for the Ninja ZX-10R is fitted as standard equipment to ensure stable damping performance even under racing conditions
    Advanced Electronic Instrumentation
    • Instrument cluster uses UV-blocking glass, so the LED displays are brighter and easier to read
    • Multifunction odometer, tripmeter, clock and lap timer/stopwatch, 90-degree, four-stroke V-twin
    Specifications
    • Engine Type: Four-stroke, liquid-cooled, DOHC, four valves per cylinder, inline-four
    • Displacement: 998cc
    • Bore x Stroke:76.0 x 55.0 mm
    • Maximum Torque: TBD
    • Compression Ratio: 13.0:1
    • Fuel Injection: DFI with 43mm Keihin throttle bodies with oval sub-throttles, two injectors per cylinder
    • Ignition: TCBI with digital advance and torque management
    • Transmission: Six-speed
    • Final Drive: TBD
    • Rake/Trail: TBD
    • Front Tire Size: 120/70 ZR17
    • Rear Tire Size: 190/55 ZR17
    • Wheelbase: TBD
    • Front Suspension / wheel travel: 43mm inverted fork with DLC coating, adjustable rebound and compression damping, spring preload adjustability and top-out springs / TBD
    • Rear Suspension / wheel travel: Bottom-Link Uni-Trak® with top-out spring, stepless, dual-range (high/low-speed) compression damping, stepless rebound damping, fully adjustable spring preload / TBD
    • Front Brake Type: Dual semi-floating 310 mm petal discs with dual four-piston radial-mount calipers
    • Rear Brake Type: Single 220mm petal disc with single-piston aluminum caliper
    • Fuel Tank Capacity: 4.5 gal.
    • Seat Height: TBD
    • Dry Weight: TBD
    • Overall length: TBD
    • Overall width: TBD
    • Overall height: TBD
    • Color: Lime Green / Flat Super Black, Metallic Diablo Black, Candy Plasma Blue / Flat Super Black
    • Warranty: 12 Months
    • Good Times™ Protection Plan: 12, 24, 36, 48 months

    Specifications

    Engine
    Engine Type Four-stroke, DOHC, four valves per cylinder, inline-four
    Displacement 998 cc
    Bore and Stroke 76.0 x 55.0 mm
    Cooling Liquid-cooled
    Compression Ratio 13.0:1
    Fuel System Fuel Injection: DFI with 43 mm Keihin throttle bodies with oval sub-throttles, two injectors per cylinder
    Ignition TCBI with digital advance and torque management
    Chassis
    Front Suspension 43 mm inverted fork with DLC coating, adjustable rebound and compression damping, spring preload adjustability and top-out springs
    Front Brakes Dual semi-floating 310 mm petal discs with dual four-piston radial-mount calipers
    Front Tire 120/70 ZR17
    Rear Suspension Bottom-Link Uni-Trak® with top-out spring, stepless, dual-range (high/low-speed) compression damping, stepless rebound damping, fully adjustable spring preload
    Rear Brakes Single 220 mm petal disc with single-piston aluminum caliper
    Rear Tire 190/55 ZR17
    Dimensions
    Dry Weight TBD
    Fuel Capacity 4.5 gal
    Wheelbase TBD
    Seat Height TBD
    Trail TBD
    Rake TBD
    Transmission
    Transmission Six-speed
    Final Drive TBD
    General
    Odometer Advanced Electronic
    Colors Lime Green / Flat Super Black, Metallic Diablo Black, Candy Plasma Blue / Flat Super Black
    Warranty 12 Months; Good Times™ Protection Plan: 12, 24, 36, 48 months

    Compare Models

    		 Print








    Year 2008
    Manufacturer Kawasaki
    Model Ninja® ZX™-10R
    Style Super Sport
    MSRP* $11,549.00
    Chassis
    Front Suspension 43 mm inverted fork with DLC coating, adjustable rebound and compression damping, spring preload adjustability and top-out springs
    Front Brakes Dual semi-floating 310 mm petal discs with dual four-piston radial-mount calipers
    Front Tire 120/70 ZR17
    Rear Suspension Bottom-Link Uni-Trak® with top-out spring, stepless, dual-range (high/low-speed) compression damping, stepless rebound damping, fully adjustable spring preload
    Rear Brakes Single 220 mm petal disc with single-piston aluminum caliper
    Rear Tire 190/55 ZR17
    Dimensions
    Dry Weight TBD
    Fuel Capacity 4.5 gal
    Wheelbase TBD
    MPG
    Seat Height TBD
    Trail TBD
    Rake TBD
    Engine
    Engine Type Four-stroke, DOHC, four valves per cylinder, inline-four
    Displacement 998 cc
    Bore and Stroke 76.0 x 55.0 mm
    Cooling Liquid-cooled
    Compression Ratio 13.0:1
    Fuel System Fuel Injection: DFI with 43 mm Keihin throttle bodies with oval sub-throttles, two injectors per cylinder
    Ignition TCBI with digital advance and torque management
    General
    Speedometer
    Tachometer
    Odometer Advanced Electronic
    Colors Lime Green / Flat Super Black, Metallic Diablo Black, Candy Plasma Blue / Flat Super Black
    Warranty 12 Months; Good Times™ Protection Plan: 12, 24, 36, 48 months
    Transmission
    Transmission Six-speed
    Final Drive TBD
